ELECTRICAL PART LIST
Resistors (continued)
Reference
Designator
Description
V
endor Part Numbe
r
V
endor Name Note
R218 OPEN NOT USED NOT USED
R219 OPEN NOT USED NOT USED
R220 1.3k RK73H1JTD1.3KF KOA
R221 OPEN NOT USED NOT USED
R222 5.1k RK73H1JTD5.1KF KOA
R223 OPEN NOT USED NOT USED
R224 OPEN NOT USED NOT USED
R225 82 Ohm RK73H1JTD82RF KOA
R226 OPEN NOT USED NOT USED
R227 68 Ohm RK73H1JTD68RF KOA
R228 560 Ohm RK73H1JTD560RF KOA
R229 240 Ohm RK73H1JTD240RF KOA
R231 680 Ohm RK73H1JTD680RF KOA
R232 680 Ohm RK73H1JTD680RF KOA
R233 680 Ohm RK73H1JTD680RF KOA
R234 680 Ohm RK73H1JTD680RF KOA
R235 680 Ohm RK73H1JTD680RF KOA
R236 680 Ohm RK73H1JTD680RF KOA
R237 680 Ohm RK73H1JTD680RF KOA
R238 680 Ohm RK73H1JTD680RF KOA
R239 560 Ohm RK73H1JTD560RF KOA
R240 240 Ohm RK73H1JTD240RF KOA
R241 39
k
RK73H1JTD39KF KOA
R242 39
k
RK73H1JTD39KF KOA
R243 39k RK73H1JTD39KF KOA
R244 10k RK73H1JTD10KF KOA
R245 10
k
RK73H1JTD10KF KOA
R246 6.8k RK73H1JTD6.8KF KOA
R247 12k RK73H1JTD12KF KOA
R248 6.8k RK73H1JTD6.8KF KOA
R249 12
k
RK73H1JTD12KF KOA
R250 12k RK73H1JTD12KF KOA
R251 6.8k RK73H1JTD6.8KF KOA
R252 6.8k RK73H1JTD6.8KF KOA
R253 12
k
RK73H1JTD12KF KOA
R256 12k RK73H1JTD12KF KOA
R257 6.8k RK73H1JTD6.8KF KOA
R258 6.8k RK73H1JTD6.8KF KOA
R259 12
k
RK73H1JTD12KF KOA
R260 12k RK73H1JTD12KF KOA
R261 6.8k RK73H1JTD6.8KF KOA
R262 12
k
RK73H1JTD12KF KOA
R263 6.8k RK73H1JTD6.8KF KOA
R264 10k RK73H1JTD10KF KOA
R265 10k RK73H1JTD10KF KOA
R266 39
k
RK73H1JTD39KF KOA
4x4 Series II PCB Assembly (optional on ESP-00 II)
