Bose ControlSpace ESP-00 II - Page 28

28
ELECTRICAL PART LIST
Resistors (continued)
Reference
Designator
Description
V
endor Part Numbe
r
V
endor Name Note
R267 39
k
RK73H1JTD39KF KOA
R268 39
k
RK73H1JTD39KF KOA
R269 4.7k RK73H1JTD4.7KF KOA
R270 1.8k RK73H1JTD1.8KF KOA
R271 1.2k RK73H1JTD1.2KF KOA
R272 4.7k RK73H1JTD4.7KF KOA
R273 4.7k RK73H1JTD4.7KF KOA
R274 1.8k RK73H1JTD1.8KF KOA
R275 1.2k RK73H1JTD1.2KF KOA
R276 4.7k RK73H1JTD4.7KF KOA
R300 OPEN NOT USED NOT USED
R301 OPEN NOT USED NOT USED
R302 0 Ohm RK73Z1JTD 0RJ KOA
R303 10k RK73H1JTD10KF KOA
R304 4.7k RK73H1JTD4.7KF KOA
R305 OPEN NOT USED NOT USED
R306 OPEN NOT USED NOT USED
R307 OPEN NOT USED NOT USED
R308 OPEN NOT USED NOT USED
R309 15
k
RK73H1JTD15KF KOA
R310 15k RK73H1JTD15KF KOA
R311 15k RK73H1JTD15KF KOA
R312 15
k
RK73H1JTD15KF KOA
R313 2.2k RK73H1JTD2.2KF KOA
R314 1k RK73H1JTD1KF KOA
R315 1k RK73H1JTD1KF KOA
R316 2.2k RK73H1JTD2.2KF KOA
R317 47 Ohm RK73H1JTD47RF RHOM
R318 47 Ohm RK73H1JTD47RF RHOM
R319 10 Ohm RK73H1JTD10RF KOA
R320 10 Ohm RK73H1JTD10RF KOA
R321 10k RK73H1JTD10KF KOA
R322 10k RK73H1JTD10KF KOA
R323 10k RK73H1JTD10KF KOA
R324 6.8k RK73H1JTD6.8KF KOA
R325 10k RK73H1JTD10KF KOA
R326 6.8k RK73H1JTD6.8KF KOA
R327 6.8k RK73H1JTD6.8KF KOA
R328 10
k
RK73H1JTD10KF KOA
R329 6.8k RK73H1JTD6.8KF KOA
R330 10k RK73H1JTD10KF KOA
R331 4.7k RK73H1JTD4.7KF KOA
R332 4.7k RK73H1JTD4.7KF KOA
R333 33 Ohm RK73H1JTD33RF KOA
R334 33 Ohm RK73H1JTD33RF KOA
R335 2.2k RK73H1JTD2.2KF KOA
4x4 Series II PCB Assembly (optional on ESP-00 II)
