ELECTRICAL PART LIST
Resistors (continued)
Reference
Designator
Description
V
endor Part Numbe
r
V
endor Name Note
R336 10
k
RK73H1JTD10KF KOA 4
R337 1.8k RK73H1JTD1.8KF KOA
R338 10k RK73H1JTD10KF KOA
R339 2.2k RK73H1JTD2.2KF KOA
R340 1.8k RK73H1JTD1.8KF KOA
R341 1.5k RK73H1JTD1.5KF KOA
R342 1.5k RK73H1JTD1.5KF KOA
R343 2.2k RK73H1JTD2.2KF KOA
R344 1
k
RK73H1JTD1KF KOA
R345 1k RK73H1JTD1KF KOA
R346 2.2k RK73H1JTD2.2KF KOA
R347 10k RK73H1JTD10KF KOA
R348 6.8k RK73H1JTD6.8KF KOA
R349 10k RK73H1JTD10KF KOA
R350 6.8k RK73H1JTD6.8KF KOA
R351 6.8k RK73H1JTD6.8KF KOA
R352 10k RK73H1JTD10KF KOA
R353 6.8k RK73H1JTD6.8KF KOA
R354 10k RK73H1JTD10KF KOA
R355 10
k
RK73H1JTD10KF KOA
R356 10k RK73H1JTD10KF KOA
R357 10 Ohm RK73H1JTD10RF KOA
R358 10 Ohm RK73H1JTD10RF KOA
R359 47 Ohm RK73H1JTD47RF RHOM
R360 47 Ohm RK73H1JTD47RF RHOM
R361 4.7k RK73H1JTD4.7KF KOA
R362 4.7k RK73H1JTD4.7KF KOA
R363 33 Ohm RK73H1JTD33RF KOA
R364 33 Ohm RK73H1JTD33RF KOA
R365 1.5k RK73H1JTD1.5KF KOA
R366 1.5k RK73H1JTD1.5KF KOA
R367 1.8k RK73H1JTD1.8KF KOA
R368 2.2k RK73H1JTD2.2KF KOA
R369 10k RK73H1JTD10KF KOA
R370 1.8k RK73H1JTD1.8KF KOA
R371 10k RK73H1JTD10KF KOA
R372 2.2k RK73H1JTD2.2KF KOA
R373 4.7k RK73H1JTD4.7KF KOA
R374 10
k
RK73H1JTD10KF KOA
R375 100 Ohm RK73H1JTD100RF KOA
R376 100 Ohm RK73H1JTD100RF KOA
R377 12
k
RK73H1JTD12KF KOA
R378 2.2k RK73H1JTD2.2KF KOA
R379 100 Ohm RK73H1JTD100RF KOA
R380 100 Ohm RK73H1JTD100RF KOA
R381 12
k
RK73H1JTD12KF KOA
4x4 Series II PCB Assembly (optional on ESP-00 II)
