ELECTRICAL PART LIST
Resistors (continued)
Reference
Designator
Description
V
endor Part Numbe
r
V
endor Name Note
R382 2.2k RK73H1JTD2.2KF KOA
R403 10
k
RK73H1JTD10KF KOA
R404 4.7k RK73H1JTD4.7KF KOA
R405 OPEN NOT USED NOT USED
R406 OPEN NOT USED NOT USED
R407 OPEN NOT USED NOT USED
R408 OPEN NOT USED NOT USED
R409 15k RK73H1JTD15KF KOA
R410 15
k
RK73H1JTD15KF KOA
R411 15k RK73H1JTD15KF KOA
R412 15k RK73H1JTD15KF KOA
R413 2.2k RK73H1JTD2.2KF KOA
R414 1
k
RK73H1JTD1KF KOA
R415 1k RK73H1JTD1KF KOA
R416 2.2k RK73H1JTD2.2KF KOA
R417 47 Ohm RK73H1JTD47RF RHOM
R418 47 Ohm RK73H1JTD47RF RHOM
R419 10 Ohm RK73H1JTD10RF KOA
R420 10 Ohm RK73H1JTD10RF KOA
R421 10
k
RK73H1JTD10KF KOA
R422 10k RK73H1JTD10KF KOA
R423 10k RK73H1JTD10KF KOA
R424 6.8k RK73H1JTD6.8KF KOA
R425 10
k
RK73H1JTD10KF KOA
R426 6.8k RK73H1JTD6.8KF KOA
R427 6.8k RK73H1JTD6.8KF KOA
R428 10
k
RK73H1JTD10KF KOA
R429 6.8k RK73H1JTD6.8KF KOA
R430 10k RK73H1JTD10KF KOA
R431 4.7k RK73H1JTD4.7KF KOA
R432 4.7k RK73H1JTD4.7KF KOA
R433 33 Ohm RK73H1JTD33RF KOA
R434 33 Ohm RK73H1JTD33RF KOA
R435 2.2k RK73H1JTD2.2KF KOA
R436 10
k
RK73H1JTD10KF KOA
R437 1.8k RK73H1JTD1.8KF KOA
R438 10k RK73H1JTD10KF KOA
R439 2.2k RK73H1JTD2.2KF KOA
R440 1.8k RK73H1JTD1.8KF KOA
R441 1.5k RK73H1JTD1.5KF KOA
R442 1.5k RK73H1JTD1.5KF KOA
R443 2.2k RK73H1JTD2.2KF KOA
R444 1k RK73H1JTD1KF KOA
R445 1k RK73H1JTD1KF KOA
R446 2.2k RK73H1JTD2.2KF KOA
R447 10
k
RK73H1JTD10KF KOA
4x4 Series II PCB Assembly (optional on ESP-00 II)
