ELECTRICAL PART LIST
Resistors (continued)
Reference
Designator
Description
V
endor Part Numbe
r
V
endor Name Note
R448 6.8k RK73H1JTD6.8KF KOA
R449 10
k
RK73H1JTD10KF KOA
R450 6.8k RK73H1JTD6.8KF KOA
R451 6.8k RK73H1JTD6.8KF KOA
R452 10
k
RK73H1JTD10KF KOA
R453 6.8k RK73H1JTD6.8KF KOA
R454 10k RK73H1JTD10KF KOA
R455 10k RK73H1JTD10KF KOA
R456 10
k
RK73H1JTD10KF KOA
R457 10 Ohm RK73H1JTD10RF KOA
R458 10 Ohm RK73H1JTD10RF KOA
R459 47 Ohm RK73H1JTD47RF RHOM
R460 47 Ohm RK73H1JTD47RF RHOM
R461 4.7k RK73H1JTD4.7KF KOA
R462 4.7k RK73H1JTD4.7KF KOA
R463 33 Ohm RK73H1JTD33RF KOA
R464 33 Ohm RK73H1JTD33RF KOA
R465 1.5k RK73H1JTD1.5KF KOA
R466 1.5k RK73H1JTD1.5KF KOA
R467 1.8k RK73H1JTD1.8KF KOA
R468 2.2k RK73H1JTD2.2KF KOA
R469 10k RK73H1JTD10KF KOA
R470 1.8k RK73H1JTD1.8KF KOA
R471 10
k
RK73H1JTD10KF KOA
R472 2.2k RK73H1JTD2.2KF KOA
R473 4.7k RK73H1JTD4.7KF KOA
R474 10
k
RK73H1JTD10KF KOA
R475 100 Ohm RK73H1JTD100RF KOA
R476 100 Ohm RK73H1JTD100RF KOA
R477 12k RK73H1JTD12KF KOA
R478 2.2k RK73H1JTD2.2KF KOA
R479 100 Ohm RK73H1JTD100RF KOA
R480 100 Ohm RK73H1JTD100RF KOA
R481 12k RK73H1JTD12KF KOA
R482 2.2k RK73H1JTD2.2KF KOA
R501 0 Ohm RK73Z1JTD 0RJ KOA
R502 OPEN NOT USED NOT USED
R503 OPEN NOT USED NOT USED
R504 10
k
RK73H1JTD10KF KOA
R505 10k RK73H1JTD10KF KOA
R506 470 Ohm RK73H1JTD470RF KOA
R507 470 Ohm RK73H1JTD470RF KOA
R508 470 Ohm RK73H1JTD470RF KOA
R509 470 Ohm RK73H1JTD470RF KOA
R510 2.7k RK73H1JTD2.7KF KOA
R511 2.7k RK73H1JTD2.7KF KOA
4x4 Series II PCB Assembly (optional on ESP-00 II)
