32
ELECTRICAL PART LIST
Resistors (continued)
Reference
Designator
Description
V
endor Part Numbe
r
V
endor Name Note
R512 5.1 Ohm RK73H1JTD5.1RF KOA
R513 OPEN NOT USED NOT USED
R514 OPEN NOT USED NOT USED
R515 5.1 Ohm RK73H1JTD5.1RF KOA
R516 2.7k RK73H1JTD2.7KF KOA
R517 2.7k RK73H1JTD2.7KF KOA
R518 470 Ohm RK73H1JTD470RF KOA
R519 470 Ohm RK73H1JTD470RF KOA
R520 470 Ohm RK73H1JTD470RF KOA
R521 470 Ohm RK73H1JTD470RF KOA
R522 33 Ohm RK73H1JTD33RF KOA
R523 330 Ohm RK73H1JTD330RF KOA
R524 330 Ohm RK73H1JTD330RF KOA
R525 0 Ohm RK73Z1JTD 0RJ KOA
R550 10k RK73H1JTD10KF KOA
R551 10
k
RK73H1JTD10KF KOA
R552 0 Ohm RK73Z1JTD 0RJ KOA
R553 0 Ohm RK73Z1JTD 0RJ KOA
R554 10k RK73H1JTD10KF KOA
R555 0 Ohm RK73Z1JTD 0RJ KOA
R556 33 Ohm RK73H1JTD33RF KOA
R557 180 Ohm RK73H1JTD180RF KOA
R558 180 Ohm RK73H1JTD180RF KOA
R559 180 Ohm RK73H1JTD180RF KOA
R560 10k RK73H1JTD10KF KOA
R561 10k RK73H1JTD10KF KOA
R562 OPEN NOT USED NOT USED
R563 180 Ohm RK73H1JTD180RF KOA
R564 OPEN NOT USED NOT USED
R565 OPEN NOT USED NOT USED
R566 0 Ohm RK73Z1JTD 0RJ KOA
R600 OPEN NOT USED NOT USED
R601 OPEN NOT USED NOT USED
R602 0 Ohm RK73Z1JTD 0RJ KOA
R603 0 Ohm RK73Z1JTD 0RJ KOA
R604 0 Ohm RK73Z1JTD 0RJ KOA
R605 0 Ohm RK73Z1JTD 0RJ KOA
R606 0 Ohm RK73Z1JTD 0RJ KOA
R607 0 Ohm RK73Z1JTD 0RJ KOA
R608 0 Ohm RK73Z1JTD 0RJ KOA
R609 0 Ohm RK73Z1JTD 0RJ KOA
R610 OPEN NOT USED NOT USED
R611 OPEN NOT USED NOT USED
R612 0 Ohm RK73Z1JTD 0RJ KOA
R613 0 Ohm RK73Z1JTD 0RJ KOA
R614 0 Ohm RK73Z1JTD 0RJ KOA
4x4 Series II PCB Assembly (optional on ESP-00 II)
