Vercise™ Deep Brain Stimulation Systems
Surgical Implant Manual
92495783-02 Page 20 of 1157
Vercise Gevia
TM
16 Contact Implantable Pulse Generator
Vercise Gevia features a 16 Contact rechargeable IPG. For instructions on charging the IPG,
refer to the Charging Handbook as listed in the DBS Reference Guide. For the programmable
characteristics of the Vercise Gevia System, refer to the Programming Manual as listed in the DBS
Reference Guide.
The Vercise Gevia IPG contains a radiopaque identication tag that is visible using standard x-ray
procedures (Figure 5).
Figure 5. Vercise Gevia Tag
The physical characteristics of the Vercise Gevia IPG are outlined in Table 31.
Table 31: Physical Characteristics
Vercise Gevia IPG (DB‑1200)
Feature Specication
Number of Contacts 16 (2 Ports)
Number of Contacts per Port 8
Case Material Titanium
Header Material Epoxy
Strain Relief Material Silicone
Dimensions 51.3 mm x 46.0 mm x 10.8 mm
Volume 19.8 cm
3
(including header)
