Product Descriptions
Surgical Implant Manual
92495783-02 Page 21 of 1157
Vercise
TM
PC Implantable Pulse Generator
Vercise PC features a 16 Contact non-rechargeable IPG. For additional information on the
Energy Use Index or the programmable characteristics of the Vercise PC System, refer to the
Programming Manual as listed in the DBS Reference Guide.
The Vercise PC IPG contains a radiopaque identication tag that is visible using standard x-ray
procedures (Figure 6).
Figure 6. Vercise PC Tag
The physical characteristics of the Vercise PC IPG are provided in Table 32.
Table 32: Physical Characteristics
Vercise PC IPG (DB‑1140)
Feature Specication
Number of Contacts 16 (2 Ports)
Number of Contacts per Port 8
Case Material Titanium
Header Material Epoxy
Strain Relief Material Silicone
Dimensions 70.9 mm x 49.5 mm x 11.3 mm
Volume 33 cm
3
(including header)
