Multi-DM™ User Manual Section 9 - DMShapes Software Overview
BMC Document Number: DOC-0009 Rev. 5.2 Page 32
9.1.2 The DMShapes Toolbar
Note that the DM Toolbar can be floated, repositioned, and hidden.
Play Press to initiate a sequence to poke all actuators in sequence
starting with actuator number 0 and ending with the highest numbered
actuator. The poke, just poked, and final actuator values after the
operation completes depend upon the starting state as follows:
• If the actuators have been set to a single value by the piston or by
the Zero button and no individual actuators changed from that
value, then the Play operation pokes each actuator at 0.8 then
returns it to its previous value.
• If the actuators have been set to a single value by the piston or by
the Zero button and one or more individual actuators changed from
that value, then the Play operation sets all actuators to the current
piston value, then pokes each actuator at 0.8 then returns it to its
previous value. When the entire cycle completes, all previous
actuator values are restored.
• If a Command Map has been applied, with or without any individual
actuator values manually changed, then the Play operation sets all
actuators to the current piston value (0.25), then pokes each
actuator at 0.8 then returns it to its previous value. When the entire
cycle completes, all previous actuator values are restored.
As this command pokes each actuator at 0.8, it has no effect if all
actuators have been set to 0.8 by the Piston or a Command Map.
