Bowers M1 - Part 1

M1 – M3 Display Units
Page 32
6.1.1. Part 1
Static = direct reading or
dynamic : Max, Min, Max-
Min, Average or Median
For measuring internal or
external diameters. It defines the
indicators colour, and gives
information to the user if the part
can be used again.
Choice of the calculation formula:
 C(1)
 C(2)
 C(1) + C(2)
 C(1) - C(2)
 -C(1)
 -C(2)
 -C(1)+C(2)
 Taper
« C » means « Channel »
It is possible to give a coefficient for each probe
from the menu
