Bowers M1 - GENERAL

M1 – M3 Display Units
Page 26
5.2. GENERAL
The following information can be seen of the upper part of the screen.
Advanced functions:
It is possible to enter a characteristic name, either with an RS232 command, or by
scanning a QR code.
After this, the characteristic name is written instead of P1 : C(1).
Name of the active
part reference an
formula. Here Part 1
with Channel 1
Static or
dynamic (Max,
Min etc…)
Unit : mm,
µm, or inch
Inside or outside
measurement
Characteristic name,
entered with RS232 or
QR code
