Register by characteristic: from 100 to 188 for the characteristic 1 and from 200
to 288 for the characteristic 2
Formula (R/W)
100
1
0 = C1
1 = C2
2 = -C1
3 = -C2
4 = C1 + C2
5 = C1 - C2
6 = -C1 + C2
7 = -C1 - C2
Maxi of a dinamical cote (R)
101
2
Mini of a dynamical cote (R)
103
2
Lower control limit (R/W)
105
2
Upper control limit (R/W)
107
2
Active class
109
1
1 à 16
Unit
110
1
0 = mm
1 = inch
2 = µm
Control limit activated
111
1
0 = no
1 = yes
resolution
112
1
1 to 5 (decimal)
State of the characteristic
113
1
0 = good
1 = < Mini
2 = > Maxi
3 = < lower ctrl limit
4 = > upper ctrl limit
Type of the characteristic
114
1
0 = Static
1 = Maxi
2 = Mini
3 = Maxi-Mini
4 = average
5 = Median
Nominal
115
2
Lower tolerance
117
2
Upper tolerance
119
2
Master value
121
2
Measure
123
2
Displayed value
Mini class 1
126
2
Mini class 2
128
2
Mini class 3
130
2
Mini class 4
132
2
Mini class 5
134
2
Mini class 6
136
2
Mini class 7
138
2
Mini class 8
140
2
Mini class 9
142
2
Mini class 10
144
2
