M1 – M3 Display Units
Page 8
The M3 is fitted with 4 thread M5 allowing to attach it. To access to these threads, it
is necessary to remove the 4 antiskid plastic parts.
It is also possible to panel mount the display, using bracket (see page 12)
Be careful not to use longer screw than M4*16.
Pneumatic connections (see also chap.4) :
Remove the
antiskid parts
to attach it on
the table
