Flight control system user manual 󾗕Agriculture
©2024 Boying General Aviation All Rights Reserved
Socket name:4G
Pin number Network name Signal direction Signal de󽗉nition
1 5V OUT Power supply 5V
2 TXD-5 OUT Send
3 RXD-5 IN Receive
4 GND OUT Ground wire
Socket name:LED
Pin number Network name Signal direction Signal de󽗉nition
1 5V OUT Power supply 5V
2 SCL-1 OUT I2C-1 clock
3 SDA-1 IN/OUT I2C-1 data
4 GND OUT Ground wire
Socket name:CAN
Pin number Network name Signal direction Signal de󽗉nition
1 CAN_H IN/OUT CAN Bus high
2 CAN_L IN/OUT CAN bus low
3 GND OUT Ground wire
Socket name:LEVEL
Pin number Network name Signal direction Signal de󽗉nition
1 5V OUT Power supply 5V
2 CURRENT IN Level signal
3
AUX_ADC1 IN
Backup AD
acquisition signal
4 GND OUT Ground wire
