DataComm & T-Block Menu Selections
Following is a list of the high-level DataComm & T-Block Menu selections and the corresponding
softkeys:
To perform formatting using the DataComm & T-Block Menu, press
MENU and the corresponding softkey:
Softkey
P-PNL
Patch Panel—The default values are as follows:
Port Width: 0.60"
Separator: LINE
Justification: CENTER, CENTER
Rotation: 90 degrees
T-BLK
Terminal Block—The default values are as follows:
Length: 0.20"
Separator: LINE
Justification: CENTER, CENTER
Rotation: 0 degrees
DESI
Desi Strip—The default values are as follows:
Width: 1.94"
Separator: NONE
Justification: CENTER, CENTER
Rotation: 90 degrees
110BLK
110 Block—The default values are as follows:
Pair Type: 4
Length: 1.2" for 4 pair (Length is based on pair configuration, so the following
applies to the other pair configurations: 2 pair = .6", 3 pair = .9", 5 pair = 1.5",
and Blank = 7.5")
Separator: LINE
Justification: CENTER, CENTER
Rotation: 270 degrees (this is the only applicable rotation available)
66BLK
66 Block—The default values are as follows:
Length: 0.20"
Separator: NONE
Justification: CENTER, CENTER
Rotation: 0 degrees
BIX
BIX Block—The default values are as follows:
Pair Type: 4
Length: 1" for 4 pair (Length is based on pair configuration, so the following
applies to the other pair configurations: 2 pair = .5", 3 pair = .75",
5 pair = 1.25", and Blank = 6.2")
Separator: LINE
Justification: CENTER, CENTER
Rotation: 270 degrees (this is the only applicable rotation available)
See Appendix B—DataComm & T-Block Menu Tree for a listing of submenus related to each
section.
12 User Manual
