B Series Degreaser Operation
Rev G Page 63
Check that the solvent being added is the same as the solvent already in the degreaser.
When changing to a new solvent, completely drain all chambers including the filter, strainer
and pumps. Perform the solvent set-up procedures as directed in Section 3.9.
Caution: Close all drain valves and install cleanout port covers and gaskets before filling to
prevent solvent spills.
4.1.3.1 Initial Filling
Add solvent to the water separator and allow it to overflow to the ultrasonic sump and the
boil sump until the boil sump is filled between 1 inch and 5 inches from the top of the
weir separating it from the ultrasonic sump. Do not pour solvent into the top of the
degreaser.
There are two acceptable methods of adding solvent:
a. Pump the solvent into the water separator drain or still return inlet. (See figure
2-2 for location of fittings.)
b. Pump the solvent through a tube placed through the countertop opening and
inserted below the surface of the water separator.
4.1.3.2 Adding Solvent After Draining the Boiling Sump
Add solvent directly into the boiling sump by pumping the solvent into the boiling sump
drain or by pumping the solvent through a tube placed through the countertop and
inserted below the surface of the boiling sump.
Note: Do not overfill the boiling sump. It will contaminate the ultrasonic sump.
Note: Check the degreaser and valves for leaks after filling.
Figure 4-1 Solvent Filling Levels
