49 Alarms
Clearway 2 User Manual
DOC-001000 Ver 6
6 Alarms
Alarm Function
The alarm function of the Clearway 2 consists of a yellow LED on the front
panel, an audible alarm and a message box on the front LCD screen. Section
3.2, Front Panel, indicates the position of the LED. The visual alarm indicators
are visible within a distance of 4 metres and to within an angle of 30
0
facing
the front panel. The operator must be within audible range to receive the
audible alarm.
Alarm Indication
Medium Priority alarm
LED – Yellow colour, one flash every 2 seconds
Audible - 3 signals repeated after a 3 second pause
Message – Yellow box on screen with information in black writing
Low Priority alarm
LED – Solid yellow
Audible – 2 signals
Message – Yellow box on screen with information in black writing
Warning message
LED – none
Audible – none
Message – Blue box on screen with description of warning.
The power fail alarm will only be indicated by a yellow flashing
LED and constant audible alarm.
