A. Main Menu
Use this menu, together with the
control panel, to choose a brewing
program (ALE, LAGER or CUSTOM)
and to set-up the Wi-Fi connection.
B. Brewing Zones
Each brewing zone will be displayed
as brewing progresses.
Brewing zones will also be used
to set custom brewing programs.
C. Temperature Display
Indicates current brew temperature and
is used to set custom temperatures.
brew is being heated towards
its target temperature
brew is being cooled towards
its target temperature
brew is within an acceptable
target temperature range
If a fault occurs, an error code will
display instead of temperature digits,
and REFER MANUAL will flash.
-- indicates temperature
more than 34°C
WARNING
Contact with hot fluids
may cause serious injury.
F indicates a fermentation test is in
progress, brew temperature is not
displayed but within acceptable
limits of the fermentation target.
D. Time Display
Indicates the total time that the
brewing program has been running.
If an error occurs, these digits may
be used to display additional error
information.
E. Wi-Fi Information
Indicates Wi-Fi and BrewArt Server
connectivity. For more information
on how to configure Wi-Fi refer to
Appendix A.
F. Brew Status Panel
Indicates overall brewing status.
G. User Prompts
Displays prompts to guide the
user through operation.
