NOTE: Hover on top of each port and clicking on it, will display the
Detailed Port Statistics Port page.
Most of the counters are self-explanatory, however the Error Counters section
are as follow:
Rx Drops: The number of frames dropped due to lack of receive
butters or egress congestion
Rx CRC/Alignment: The number of frames received with Cyclic
Redundancy Check or alignment errors
Rx Undersize: The number of short frames received with valid
CRC.
NOTE: short frames are frames that are smaller than 64 bytes.
Rx Oversize: The number of long frames received with valid CRC.
NOTE: Long frames are frames that are longer than the configured
maximum frame length for this port.
Rx Fragments: The number of short frames received with invalid
CRC.
Rx Jabber: The number of long frames received with invalid CRC
Rx Filtered: The number of received frames filtered by the
forwarding process.
Tx Drops: The number of frames dropped due to output buffer
congestion.
Tx Late/Exc. Coll.: The number of frames dropped due to
excessive or late collisions.
Port Selection: This pull down menu allows the selection of any
of the other 10 ports.
Auto-refresh check box: Selecting this box, will refresh the page
every 3 seconds.
Refresh button: Refresh the page manually/immediately
Clear button: Clears all counters for the selected port.
Maintenance
This section allows the physical manipulation of the device/unit/radio. Restart,
Factory Defaults, Software and Configuration upload and download are all
perform under this section.
Restart Device
