Broadcom NetXtreme BCM57 Series User Manual

Broadcom Gigabit Ethernet Teaming ServicesNetXtreme User Guide
Broadcom
®
April 2017 • 2CS57XX-CDUM514-R Page 122
Figure 5: Teaming Across Switches Without an Interswitch Link
The addition of a link between the switches allows traffic from/to Blue and Gray to reach each other without any
problems. Note the additional entries in the CAM table for both switches. The link interconnect is critical for the
proper operation of the team. As a result, it is highly advisable to have a link aggregation trunk to interconnect
the two switches to ensure high availability for the connection.
Figure 6: Teaming Across Switches With Interconnect
Blue
SLB Team
192.168.1.101
Gray
SLB Team
192.168.1.102
ARP Table
100 = 49:C9
102 = 5E:CA
ARP Table
100 = 49:C9
101 = 82:82
Red
SLB Team
192.168.1.100
Top Switch
CAM Table:
Eth 1: 82:83
Eth2: 49:C9
Eth 4: 5E:C9
Bottom Switch
CAM Table:
Eth 1: 82:83
Eth2: 49:C8
Eth 4: 5E:CA
ARP Table
101 = 82:82
102 = 5E:CA
Cannot ping
82:82 (P) 5E:C9 5E:CA (P)
4
2
49:C9(P) 49:C8
1
2
4
1
82:83
Blue
SLB Team
192.168.1.101
Gray
SLB Team
192.168.1.102
ARP Table
100 = 49:C9
102 = 5E:CA
ARP Table
100 = 49:C9
101 = 82:82
Red
SLB Team
192.168.1.100
Top Switch
CAM Table:
Eth 1: 82:83
Eth2: 49:C9
Eth 4: 5E:C9
Eth 24: 82:82
Eth 24:49:C8
Eth 24: 5E:CA
Eth 24: A2:A12*
Bottom Switch
CAM Table:
Eth 1: 82:83
Eth2: 49:C8
Eth 4: 5E:CA
Eth 24: 82:83
Eth 24: 49:C9
Eth 24: 5E:C9
Eth 24: B0:30
ARP Table
101 = 82:82
102 = 5E:CA
82:82 (P) 5E:C9 5E:CA (P)
4
2
49:C9(P) 49:C8
1
2
4
1
82:83
24 24
*Bottom Switch Port 24
MAC Address
*Top Switch Port 24 MAC
Address
