Broaster VF-2 - Page 73

6-6
Troubleshooting flow chart - sheet 3
Yes Yes
No No
Yes Yes Yes Yes
No No No No
Yes Yes
No No
Yes
No
Yes
No
Is 120VAC
present
between
wires 68 &
28?
Trace lost
connection
Replace
Hi-Limit
Relay
Replace I/O board
Is Product Door
light lit red?
7
8
Is Hi-Limit
Tripped?
Reset &
monitor
Is C2
closed?
Do
elements
heat?
Is 120VAC present
between wires 21
& neutral for 1
second?
Is 12VDC present
between wires 1 &
2 for one second?
Replace
controller
Does basket drop
when "Start"
button is pushed?
Is 120VAC
present at
C2 coil?
Replace
C2
Check
element
Replace
motor
Replace
Relay
9
Is Product Door
open?
Troubleshoot
Interlock
Close
door
