Brooks LF80C - Error Codes

Brooks Automation
278580 Revision A 143
LF80C ZeniD RFID Reader 8 Service and Troubleshooting
Product Manual 8.4 Error Codes
8.4 Error Codes
8.4.1 Error ID and Alarm ID
ID Name Description Possible cause Correcting action
0 none no error not used no
1 auto fail automatic reading is
not possible *
reader is still busy
with a former read or
write request
wait until the former request is
done
2 ex fail read or write initiated
from the host and/or
other actions cannot be
carried out *
reader is still busy
with a former read or
write request
wait until the former request is
done
3 write fail data transfer to the
transponder not possi-
ble *
reader is still busy
with a former read or
write request
wait until the former request is
done
4 no tag
no transponder or
antenna is installed
no readable tag within
the reading range
put a transponder into the
antenna range, verify type and
function of the transponder
antenna is not
connected correctly
check antenna connection
antenna and
transponder are in a
bad orientation
check orientation between
antenna and transponder (see
Î
Antenna Installation)
antenna is not tuned perform an antenna tuning
disturbing field at
transmitting
frequency
check antenna surroundings for
possible disturbing sources
(monitors, servo motors, ...)
antenna is damaged
or too close to metal
exchange antenna, verify
antenna installation
5 invalid
invalid parameter or
data
data sent with a
command are wrong
check syntax and data of
command
sent parameter is not
implemented or is out
of range
check syntax and value of
parameter
6 unknown unknown error not used no
7 unconfig the device is not
configured
wrong reader address
is sent
check syntax of message,
check parameter F „Reader
address“
