5 Product Specifications LF80C ZeniD RFID Reader
5.2 Indicating and Operating Elements Product Manual
5.2 Indicating and Operating Elements
1
2
3
4
5
6
7
9
10
11
12
13
14
15
8
1 External Output LED 9 Test mode button
2 Read button 10 Test L ED
3 Status LEDs 11 Read LED
4 Write button 12 Tuning button
5 Traffic LED 13 Tuning LED
6 Power LED 14 Antenna LED
7 Link LED 15 Input LED
8 Write LED
