Brooks Automation
30 278580 Revision A
6 Installation LF80C ZeniD RFID Reader
6.4 Assembly of the Device Product Manual
6.4.2 Housing Without Mounts
If you intend to install the device without mounts, you will have to remove
the housing lid.
 Screw the device onto the assembly surface.
 Connect the device as described in the section
Indicating
and Operating Elements.
CAUTION
Static electricity can damage electronic components in the device. All
persons installing or maintaining the device must be trained in ESD
protection.
When removing the housing lid, note that the housing lid may be
connected to the case with a cable. Remove the lid carefully to prevent
damage - do not pull on it.
