Brooks Automation
22 278580 Revision A
5 Product Specifications LF80C ZeniD RFID Reader
5.6 Antenna Cable Product Manual
5.6 Antenna Cable
5.6.1 Cable for Rod Antenna and Frame Antenna
5.6.2 Cable for Mini Antenna and Micro Antenna
Standard cable
Diameter 5.6 mm
Bending radius 84 mm
If the device is installed immediately and the
cable is therefore only bent one single time, a
bending radius of 33 mm is permitted.
Material PVC
Approvals VDE, IEC, UL
Highly flexible cable (suitable for energy chains)
Diameter 6 mm
Bending radius 60 mm
Material PVC
Approvals VDE, IEC, UL
Standard cable
Diameter 4.1 mm
Bending radius 41 mm
If the device is installed immediately and the
cable is therefore only bent one single time, a
bending radius of 20.5 mm is permitted.
Material PVC
Approvals VDE, IEC, UL
