6 Installation LF80C ZeniD RFID Reader
6.10 Commissioning Product Manual
6.10 Commissioning
6.10.1 Required Operating Conditions
To operate the reader, the following requirements must be met:
6.10.2 Tuning
Before the reader can be operated, it must be calibrated so that it can
communicate with the transponder.
 An antenna must be connected correctly to the reader.
 The power supply must be connected.
 The transponder must be located within the individual
reading/writing range of the antenna.
 A host must be connected to the reader.
 Press the Tuning button (see
Î
Indicating and Operating
Elements). The Tuning LED lights up and goes off again. A
flashing LED indicates a malfunction (see
Î
Service and
Troubleshooting).
