LF80C ZeniD RFID Reader 6 Installation
Product Manual 6.5 Antenna Installation
6.5.2 Available Antenna Types
Different types of antennas are available on request.
Perpendicular The illustration shows
the optimal position of
the transponder if it is
perpendicular to the
axis of the antenna.
Perpendicular
(frame
antenna)
The illustration shows
the optimal position of
the transponder if it is
perpendicular to the
axis of a frame
antenna.
