7 Operation LF80C ZeniD RFID Reader
7.2 Operation of the ASC-I1 Protocol Product Manual
7.2.4 Parameter
Parameter 0 (0x00) Sensor delay
Operation delay for the presence sensor.
01 .. 99 (0.1 seconds)
Default: 10 (1s)
Parameter 1 (0x01) Read mode
Readmode for automatic read triggered by external input.
00 - read only one page
01 - read until end character or empty character
2)
02 - read all pages
10 - read only one page with sensor check first
1)
11 - read until end/empty character with sensor check first
1) 2)
12 - read all pages with sensor check first
1)
99 - deactivate sensor
1)
If the sensor check is activated, the status of a floating contact
connected to the external input is checked before a reading process
(writing process) is triggered. If it is not connected, the error message
"NOTAG" is sent, otherwise the read respectively write process is started.
2)
'E' respectively 'F' in ID Bit 0...3 of the reading ID
Default: 00 (read only one page)
Parameter 2 (0x02) Read page
Page for readmode "00".
01 .. 17 - Page of multipage transponder
Default: 01 (page 1 of multipage transponder)
Parameter 3 (0x03) r/w repeat time
No. (dec.) No. (hex) Parameter name
0 0x00
Î
Sensor delay
1 0x01
Î
Read mode
2 0x02
Î
Read page
3 0x03
Î
r/w repeat time
4 0x04
Î
r/w max repeat
5 0x05
Î
RS232 repeat time
6 0x06
Î
RS232 max repeat
7 0x07
Î
Watch port
F
Î
Reader address
