7 Operation LF80C ZeniD RFID Reader
7.2 Operation of the ASC-I1 Protocol Product Manual
G - Request
parameter value
The command G is used to request the value of all public parameters of the
device.
The reader sends an individual protocol package for each available public
parameter. After the last parameter the reader finally sends an additional
package. The message includes the command 'g' and the source address
'0'..'E'.
Host → Reader
CMD Reader ID
G1 byte
Reader → Host
CMD Reader ID Parameter No. Parameter value
g 1 byte 1 byte 2 bytes
