7 Operation LF80C ZeniD RFID Reader
7.2 Operation of the ASC-I1 Protocol Product Manual
A - Sensor event If
Î
Parameter 7 (0x07) is activated ('01'), the reader reports the release
event of the external sensor. The event message must be confirmed by the
host.
If the host does not send an acknowledge message, the message is
repeated (
Î
Parameter 6 (0x06)) in the defined time frame (
Î
Parameter 5
(0x05)).
Reader → Host
CMD Reader ID
A1 byte
Host → Reader
CMD Reader ID
a1 byte
