Brooks Automation
278580 Revision A 87
LF80C ZeniD RFID Reader 7 Operation
Product Manual 7.3 Operation of SECS Protocol
Acknowledge code for ON-LINE request.
0 ON-LINE accepted (reader is online)
Where used S1F18
Page number of multipage, read/only and read/write transponders
0x00 : First page of the data area of a multipage transponder.
Multipage transponder (pages 1 to 17):
If only one page of the multipage transponder is read, note the following:
0x01 : (1) page 1 0x81 : (129) locked page 1
... ...
0x11 : (17) page 17 0x91 : (146) locked page 17
Read-only transponder:
0xF0 : (240) Read one page only
Read/write transponder:
0xF1 : (241) Read or write one page only
Where used S3F11
The transponder data that has been read or will be written. The PAGEDATA
corresponds to the value of a transponder page.
PAGEDATA [0] Corresponds to the page number. The value of the page
number is displayed in the data item "PAGE_ID".
PAGEDATA [1] The 8 bytes (one page) of the transponder ID follow.
PAGEDATA [8]
Where used S3F7, S3F12, S3F13, S3F65
ONLACK Format: B[1]
PAGE_ID Format: B[1]
PAGEDATA Format: B[9]
