1. Introduction
TheBrooksAutomationTopCooler™offersmaximumperformancewithminimumcomplexity
throughadrop-ininterfaceintotheTransportChamber.Simplifiedgasassistedcoolingandno
onboardcontrolelectronicsfurtheraddtominimumcomplexity.Easyaccessisprovidedtoall
serviceableareas,suchasthecoolplate,whencleaningisnecessary.

Figure 1-1: TopCooler Overview
Annotation Description
A CoolChuckAssembly
B ChargeValves
C CoolGasConnection
D PoppetAssembly
TheTopCoolerisasimple,highlyefficient,gas-assistedwafercoolingchambercontrolledbyfive
bitsofdigitalI/OconnecteddirectlytotheTransportModuleController.TheTopCoolerisdesigned
