4. Maintenance and Repair VX TopCooler
TopCooler Replacement Part Number: 606325 Rev. A
TopCooler Replacement
Thedrop-inTopCoolerisdesignedforeasyreplacementoftheentireassemblytominimizedown
time.Nore-alignmentisrequiredafterreplacement.
RequiredTools
l
MetricHexWrenches
LimitsandTolerances
Thefacet-mountedTopCoolerinthesystemisselfaligningandrequiresnoadjustmentsafter
installation.
ReplacementStrategy
TheTopCoolerisremovedintwosubassemblieswithfourscrewseach.Turnoffanddisconnectall
power,communications,andairconnectionsasdetailedintheShut-downprocedureofthesystem
manual.
Lockout / Tagout
Workingwithenergizedequipmentmaycausesuddenmovementorelectricalshockand
mayresultindeathorseriousinjury.
l
Allenergymustberemovedfromtheequipmentperthefacility’s
Lockout/Tagoutprocedurebeforeservicing.
l
Iflocalproceduresarenotavailable,followtheprocedureforLockout/Tagoutin
OSHA Standard 29CFR 1910.147.

Unauthorized Service
Personalinjuryordamagetoequipmentmayresultifthisproductisoperatedorserviced
byunauthorizedpersonnel.
l
Onlyqualifiedpersonnelareallowedtotransport,assemble,operate,ormaintain
theProduct.
l
Properlyqualifiedpersonnelarethosewhohavereceivedcertifiedtrainingand
havetheproperqualificationsfortheirjobs.
30
