Part Number: 606325 Rev. A TopCooler Replacement

Thesystemmaybeusedinanenvironmentwherehazardousmaterialsarepresent,
andsurfacesmaybecontaminatedbythosematerials.

Whenthisisthecase,refertothefacility’sMaterialSafetyDataSheetsforthose
materialstodetermineproperhandlingandfollowthefacility’sprocedurestocertify
theenvironmentissafe.

RemovalProcedure
Figure 4-1: Removing the TopCooler
Step Action
1.
Critical Safety Step!
DisconnectthetwoairconnectionsandthecommunicationconnectionattheCableFittingMounton
thetopoftheassembly.Disconnectthegasconnectionsfromthebottomoftheassembly.
