Brother HL-L2300d Series Service Manual

2-18
Confidential
Error
codes
Description
Refer
to:
Error
codes
Description
Refer
to:
E500
An error occurred during access to the
DRAM in the main PCB ASSY.
2-57
FB06 ―
E600
Write error in the EEPROM of the
main PCB ASSY
2-57
FB07 ―
E701
Irregular operation of the flash ROM
file system on the main PCB.
2-57
FB08 ―
E702
Read error in the flash ROM on the
main PCB
2-57
FB09 ―
E900 ― FB0A ―
EC00 ― FB0B ―
F900
The country code was not entered
correctly.
2-57
FB0C ―
FA01 ― FB0D ―
FA02 ― FB0F ―
FA03 ― FC01 ―
FB01 ― FC02 ―
FB02 ― FC03 ―
FB03 ― FC04 ―
FB04 ― FC05 ―
FB05 ―

Brother HL-L2300d Series Specifications

General

Functions	Print
Standard Paper Capacity (sheets)	250
Standard Interface(s)	USB 2.0
Print Resolution (maximum dpi)	2400 x 600 dpi
Recommended Monthly Print Volume	250 - 2, 000 pages
Operating System Compatibility	Windows, Mac, Linux
