Brother MFC-9330CDW Network User's Guide

Web Based Management
67
5
Understanding Error Messages 5
You can confirm the error status on the Touchscreen of your machine or Connection Status in Web Based
Management.
 Server Timeout, contact your administrator.
This message will appear when you cannot connect to the server.
Make sure that:
• Your server address is correct.
• Your server is connected to the network.
• The machine is connected to the network.
 Authentication Error, contact your administrator.
The message will appear when your Authentication Setting is not correct.
Make sure that:
• The Username
1
and Password in Authentication Setting are correct.
1
If the username is part of a domain, please input the username in one of the following styles: user@domain or domain\user.
• The time of the log file server matches the time from the SNTP server, or the Date&Time settings.
• The SNTP time server settings are configured correctly so the time matches the time used for
authentication by Kerberos or NTLMv2. If there is no SNTP server, make sure the Date&Time and
Time Zone settings are set correctly using Web Based Management or the control panel so the
machine matches the time being used by the server providing the authentication.
 File Access Error, contact your administrator.
This message will appear when you cannot access the destination folder.
Make sure that:
• The store directory name is correct.
• The store directory is write-enabled.
• The File is not locked.
 Wrong Date&Time, contact your administrator.
This message will appear when your machine does not obtain the time from the SNTP time server. Make
sure that:
• The settings to access the SNTP time are correct using Web Based Management.
• In Web Based Management, confirm the Date & Time settings of your machine are correct.
NOTE
If you choose the Cancel Print option in Web Based Management, the Log Access Error message
will remain on the Touchscreen for about 60 seconds.

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
