Control panel setup
102
6
Fax to Server 6
The Fax to Server feature allows the machine to scan a document and send it over the network to a separate
fax server. The document will then be sent from the server as fax data to the destination fax number over
standard phone lines. When the Fax to Server feature is set to ON all automatic fax transmissions from the
machine will be sent to the fax server for fax transmission. You can continue to send a fax directly from the
machine using the manual fax feature (For more information, see Sending a fax manually in the User’s
Guide).
To send a document to the fax server the correct syntax for that server must be used. The destination fax
number must be sent with a prefix and a suffix that match the parameters used by the fax server. In most
cases the syntax for the prefix is “fax=” and the syntax for the suffix would be the domain name of the fax
server E-mail gateway. The suffix must also include the “@” symbol at the beginning of the suffix. The prefix
and the suffix information must be stored in the machine before you can use the fax to server function.
Destination fax numbers can be saved in the One-Touch or Speed Dial locations or entered using the dial
pad (up to 20 digit numbers). For example if you wanted to send a document to a destination fax number of
123-555-0001 the following syntax would be used.
Note
Your fax server application must support an E-mail gateway.
Setting Fax to Server to On 6
You can store the prefix/suffix address for the fax server in the machine.
a Press Menu.
b Press a or b to choose LAN.
Press OK.
c Press a or b to choose Fax to Server.
Press OK.
d Press a or b to choose On.
Press OK.
e Press a or b to choose Prefix.
Press OK.
f Enter the prefix using dial pad.
g Press OK.
h Press a or b to choose Suffix.
Press OK.
