Brother MFC-9970CDW User Manual

120
Sending faxes
Difficulties Suggestions
Poor sending quality. Try changing your resolution to Fine or S.Fine. Make a copy to check your
machine’s scanner operation. If the copy quality is not good, clean the scanner.
(See Cleaning the scanner in Appendix A of the Advanced User's Guide.)
Transmission Verification Report
says RESULT:NG.
There is probably temporary noise or static on the line. Try sending the fax again.
If you are sending a PC-Fax message and get RESULT:NG on the Transmission
Verification Report, your machine may be out of memory. To free up extra
memory, you can turn off fax storage (see Changing Remote Fax Options in
Chapter 4 of the Advanced User's Guide), print fax messages in memory (see
Printing a fax from the memory in Chapter 4 of the Advanced User's Guide) or
cancel a delayed fax or polling job (see Checking and canceling waiting jobs in
Chapter 3 of the Advanced User's Guide). If the problem continues, ask the
telephone company to check your telephone line.
If you often get transmission errors due to possible interference on the telephone
line, try changing the Compatibility setting to Basic(for VoIP). (See
Telephone line interference / VoIP on page 126.)
Sent faxes are blank. Make sure you are loading the document properly. (See Loading documents
on page 26.)
Vertical black lines when sending. Black vertical lines on faxes you send are typically caused by dirt or correction fluid
on the glass strip. (See Cleaning the scanner in Appendix A of the Advanced
User's Guide.)
Cannot send a fax. Contact your administrator to check your Secure Function Lock Settings.
Handling incoming calls
Difficulties Suggestions
The machine ‘Hears’ a voice as a
CNG Tone.
If Easy Receive is set to On, your machine is more sensitive to sounds. It may
mistakenly interpret certain voices or music on the line as a fax machine calling
and respond with fax receiving tones. Deactivate the machine by pressing
Stop/Exit. Try avoiding this problem by turning Easy Receive to Off. (See Easy
Receive on page 36.)
Sending a Fax Call to the machine. If you answered on an external or extension telephone, press your Fax Receive
Code (default setting is l51). When your machine answers, hang up.
Custom features on a single line. If you have Call Waiting, Call Waiting/Caller ID, Caller ID, RingMaster, Voice Mail,
an answering machine, an alarm system or other custom feature on a single
telephone line with your machine, it may create a problem sending or receiving
faxes.
For Example: If you subscribe to Call Waiting or some other custom service and
its signal comes through the line while your machine is sending or receiving a fax,
the signal can temporarily interrupt or disrupt the faxes. Brother’s ECM feature
should help overcome this problem. This condition is related to the telephone
system industry and is common to all devices that send and receive information
on a single, shared line with custom features. If avoiding a slight interruption is
crucial to your business, a separate line with no custom features is recommended.
Copy difficulties
Difficulties Suggestions
Cannot make a copy.
 Make sure that COPY is illuminated. (See How to copy on page 53.)
 Contact your administrator to check your Secure Function Lock Settings.

Brother MFC-9970CDW Specifications

General

Weight (imperial)	62.8 lbs
Dimensions (WxDxH)	490 x 526 x 531 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	copy, fax, print, scan
Compatible operating systems	Windows, Mac OS
Dimensions (W x D x H) (imperial)	19.3 x 20.7 x 20.9 \
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	30 ppm
Digital sender	No
Printing colors	Black, Blue, Red, Yellow
Maximum duty cycle	60000 pages per month
Optional functions	Fax
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	30 cpm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR, USB
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Display	LCD
Control type	Touch
Display diagonal	5 \
Market positioning	Business
Direct printing	-
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Authentication method	WEP 64/128-b, WPA-PSK (TKIP/AES), WPA2-PSK (AES), 802.1x (LEAP, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS)
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, WINS/NetBIOS, DNS, mDNS, LLMNR, LPR/LPD, IPP/IPPS, FTP, CIFS, TELNET, SNMPv1/v2c/v3, HTTP/HTTPS, TFTP, SMTP, ICMP, LLTD, SNTP, APOP, POP, SMTP-AUTH, SSL/TLS (IPPS, HTTPS, SMTP, POP), 802.1x
Supported network protocols (IPv6)	NDP, RA, DNS, mDNS, LLMNR, LPR/LPD, IPP/IPPS, FTP, CIFS, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS, TFTP, SMTP, ICMPv6, SNTP, LLTD, APOP, POP, SMTP-AUTH, SSL/TLS (IPPS, HTTPS, SMTP, POP), 802.1x
Maximum internal memory	512 MB
Sound pressure level (copying)	57 dB
AC input voltage	110 - 120 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1.8 W
Power consumption (average operating)	615 W
Package weight	34019 g
Operating temperature (T-T)	50 - 90.5 °F
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR
