Brother MFC-9970CDW User Manual

General Setup
5
1
LCD screen 1
Setting the backlight
brightness 1
You can adjust the brightness of the LCD
backlight. If you are having difficulty reading
the LCD, try changing the brightness setting.
a Press MENU.
b Press a or b to display
General Setup.
Press General Setup.
c Press a or b to display LCD Settings.
Press LCD Settings.
d Press Backlight.
e Press Light, Med or Dark.
f Press Stop/Exit.
Setting the Dim Timer for the
backlight 1
You can set how long the LCD backlight stays
on after you go back to the Ready screen.
a Press MENU.
b Press a or b to display
General Setup.
Press General Setup.
c Press a or b to display LCD Settings.
Press LCD Settings.
d Press Dim Timer.
e Press Off, 10 Secs, 20 Secs or
30 Secs.
f Press Stop/Exit.
Dial Prefix 1
The Dial Prefix setting will automatically dial a
predefined number before every fax number
you dial. For example: If your telephone
system requires a 9 to dial an outside number
use this setting to automatically dial 9 for
every fax you send.
Setting up the prefix number 1
a Press MENU.
b Press a or b to display
Initial Setup.
Press Initial Setup.
c Press a or b to display Dial Prefix.
Press Dial Prefix.
d Do one of the following:
 If you want to set the dial prefix
feature to on, press On. Go to
step e.
 If you want to set the dial prefix
feature to off, press Off. Go to
step g.
e Press Dial Prefix.
f Enter the prefix number (up to 5 digits)
by pressing the buttons on the
Touchscreen.
Press OK.
Note
• You can use the numbers and symbols 0
to 9, #, and l. (You cannot use ! with any
other numbers or symbols.)
• If your telephone system requires a time
break recall (hookflash), press ! to enter
the break.
• (Canada only) If pulse dialing mode is on,
# and l are not available to use.
g Press Stop/Exit.

Brother MFC-9970CDW Specifications

General

Weight (imperial)	62.8 lbs
Dimensions (WxDxH)	490 x 526 x 531 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	copy, fax, print, scan
Compatible operating systems	Windows, Mac OS
Dimensions (W x D x H) (imperial)	19.3 x 20.7 x 20.9 \
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	30 ppm
Digital sender	No
Printing colors	Black, Blue, Red, Yellow
Maximum duty cycle	60000 pages per month
Optional functions	Fax
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	30 cpm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR, USB
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Display	LCD
Control type	Touch
Display diagonal	5 \
Market positioning	Business
Direct printing	-
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Authentication method	WEP 64/128-b, WPA-PSK (TKIP/AES), WPA2-PSK (AES), 802.1x (LEAP, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS)
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, WINS/NetBIOS, DNS, mDNS, LLMNR, LPR/LPD, IPP/IPPS, FTP, CIFS, TELNET, SNMPv1/v2c/v3, HTTP/HTTPS, TFTP, SMTP, ICMP, LLTD, SNTP, APOP, POP, SMTP-AUTH, SSL/TLS (IPPS, HTTPS, SMTP, POP), 802.1x
Supported network protocols (IPv6)	NDP, RA, DNS, mDNS, LLMNR, LPR/LPD, IPP/IPPS, FTP, CIFS, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS, TFTP, SMTP, ICMPv6, SNTP, LLTD, APOP, POP, SMTP-AUTH, SSL/TLS (IPPS, HTTPS, SMTP, POP), 802.1x
Maximum internal memory	512 MB
Sound pressure level (copying)	57 dB
AC input voltage	110 - 120 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1.8 W
Power consumption (average operating)	615 W
Package weight	34019 g
Operating temperature (T-T)	50 - 90.5 °F
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR
