Brother MFC-B7720DN Service Manual

1-7
Confidential
Model MFC-7390 MFC-7490D
MFC-B7715DW
MFC-B7720DN
MFC-L2715D
MFC-L2716D
MFC-L2690DW
MFC-L2710DN
MFC-L2710DW
MFC-L2712DN
MFC-L2712DW
MFC-L2713DW
MFC-L2715DW
MFC-L2716DW
MFC-L2717DW
Warm up Time
(From Sleep Mode)
Less than 9 sec. at 73.4F / 50% (23°C / 50%)
Warm up Time
(From Power ON)
Less than 27 sec.
at 73.4F / 50% (23°C / 50%)
Less than 27 sec. at 73.4F /
50% (23°C / 50%)
(MFC-B7715DW for EU,
L2715D, L2716D)
Less than 28 sec. at 73.4F /
50% (23°C / 50%)
(MFC-B7715DW for ASA,
B7720DN)
Less than 28 sec. at 73.4F / 50%
(23°C / 50%)
FPOT
(From Ready Mode
and Standard Tray)
Less than 8.5 sec. at 73.4F (23°C) / 230V
FPOT
(From Sleep Mode
and Standard Tray)
Less than 17.5 sec. at 73.4F (23°C) / 230V
Mono Print Speed
(A4/Letter)
Up to 30/32 ppm
(Quiet Mode: Up to 13/13 ppm)
Up to 34/36 ppm
(Quiet Mode: Up
to 13/13 ppm)
Up to 30/32 ppm
(Quiet Mode: Up to 13/13 ppm)
(for MFC-L2710DN, L2710DW,
L2712DN, L2712DW)
Up to 26/26 ppm
(Quiet Mode: Up to 13/13 ppm)
(for MFC-L2690DW)
Up to 34/36 ppm
(Quiet Mode:
Up to 13/13 ppm)
Full Color Print
Speed (A4/Letter)
N/A
Mono Duplex Print
Speed (A4/Letter)
N/A
15/15 sides per minute
(7.5/7.5 sheets
per minute)
16/17 sides per minute
(8/8.5 sheets per
minute)
15/15 sides per minute
(7.5/7.5 sheets
per minute)
16/17 sides per minute
(8/8.5 sheets per
minute)
Full Color Duplex Print
Speed (A4/Letter)
N/A
Processor 600 MHz
Back up Clock Up to 2 hours
Carton Dimensions
(W x D x H)
580 x 570 x 434 mm
22.8" x 22.4" x 17.1"
580 x 517 x 434 mm
22.8" x 20.4" x 17.1"
(except for MFC-B7720DN)
580 x 570 x 434 mm
22.8" x 22.4" x 17.1"
(MFC-B7720DN)
580 x 517 x 434 mm
22.8" x 20.4" x 17.1"
Machine Dimensions
(W x D x H)
481 x 398.5 x 318.5 mm
18.9" x 15.7" x 12.5"
410 x 398.5 x 318.5 mm
16.1" x 15.7" x 12.5"
(except for MFC-B7720DN)
481 x 398.5 x 318.5 mm
18.9" x 15.7" x 12.5"
(MFC-B7720DN)
410 x 398.5 x 318.5 mm
16.1" x 15.7" x 12.5"
Weight w/ Carton TBD TBD
15.0 kg / 33.0 lb
(MFC-B7715DW for ASA)
15.1 kg / 33.3 lb
(MFC-B7715DW for EU)
15.5 kg / 34.3 lb
(MFC-B7720DN)
TBD
(MFC-L2715D, L2716D)
14.7 kg / 32.5 lb
(MFC-L2710DN, L2710DW
for US/EU/OCE(ARL))
14.9 kg / 32.8 lb
(MFC-L2712DN, L2712DW)
TBD
(MFC-L2690DW, L2710DW
for LTN)
14.7 kg / 32.5 lb
(MFC-L2713DW, L2715DW
for TWN, L2717DW)
14.8 kg / 32.6 lb
(MFC-L2715DW for KOR,
L2716DW)
15.1 kg / 33.3 lb
(MFC-L2715DW for ASA)
Weight w/o Carton,
w/ toner/drum
TBD TBD
12.0 kg / 26.5 lb
(MFC-B7715DW)
12.1 kg / 26.7 lb
(MFC-B7720DN)
TBD
(MFC-L2715D, L2716D)
11.8 kg / 26.0 lb
(except for MFC-L2690DW,
L2710DW for LTN)
TBD
(MFC-L2690DW, L2710DW
for LTN)
11.8 kg / 26.0 lb
(MFC-L2713DW, L2715DW
for KOR/TWN, L2716DW,
L2717DW)
12.0 kg / 26.5 lb
(MFC-L2715DW for ASA)
Weight w/o Carton
and toner/drum
TBD TBD
10.9 kg / 24.0 lb
(MFC-B7715DW for EU)
11.1 kg / 24.5 lb
(MFC-B7715DW for ASA)
11.2 kg / 24.7 lb
(MFC-B7720DN)
TBD
(MFC-L2715D, L2716D)
10.7 kg / 23.6 lb
(MFC-L2710DN, L2710DW
for EU, L2712DN, L2712DW)
10.9 kg / 24.0 lb
(MFC-L2710DW for US/
OCE(ARL))
TBD
(MFC-L2690DW, L2710DW
for LTN)
10.7 kg / 23.6 lb
(MFC-L2715DW for ASA)
10.9 kg / 24.0 lb
(MFC-L2713DW, L2715DW
for KOR/TWN, L2716DW,
L2717DW)
Specifications are subject to change without notice.
