3-13
Confidential
Harness colors may be changed for any reason.
* Center thermistor has a black and blue connectors (230V models only). The black connector may be
connected to the blue insertion port and vice versa.
5 Back Cover Sensor ASSY
6 Eject Sensor PCB ASSY, Fuser Unit
Front
Front
“A”
“B”
Hook
Hole
Hook
CN3
A view
<A view>
Main frame L ASSY
Back cover
sensor harness
Back cover
sensor ASSY
Main PCB
(BL)
Hole C
ASSY
<B view>
B view
Front
“A”
“B”
Hook D
Hook
Hook
Paper
eject
ASSY
Joint cover
base ASSY
Hole C
Hook D
Hook
Front
A view
<A view>
Main PCB ASSY
Eject sensor PCB ASSY
*
Main frame L ASSY
Eject sensor harness ASSY
(RD, WH, BL)
“A”
Hole
Front
“A”
Hole
Fuser unit
CN1
CN2
Hook
Guide
Side thermistor
harness
Cutout
harness
*
CN42
Center thermistor
