(6) Remove the Registration gear Z26-23 from the Registration/pinch roller gear bushing.

Fig. 3-238

(7) Remove the Pinch roller drive gear Z21M05 from the Registration/pinch roller gear bushing.

Fig. 3-239

Registration gear Z26-23

Registration/pinch

roller gear bushing

Pinch roller drive gear Z21M05

Registration/pinch

roller gear bushing
