12 Sync Pre-Installation
AUDIO/VIDEO
NOTE:TheVideoDistributionCentercanacceptavarietyofsignalsourcessuchassatellite
boxes,cableset-topboxes,orDVD/Blu-rayplayers.Theaudioandvideofromeach
sourceisconnectedtoamodulatorthat“assigns”aunique“TV”channeltothe
source.Thenumberofmodulatorspresentinthesystemisdeterminedbythenumber
ofvideosourcestothatwillbeavailablefordisplayonthemonitors.Whenchoosing
modulators,itisimportanttoconsidertheconnectiontypeavailableonthesignal
source,theoutputqualityofthemodulator(StandardorHighDenition).
Three different modulators are available.
MODULATOR AVAILABLE VIDEO
INPUT CONNECTIONS
AVAILABLE AUDIO
INPUT CONNECTIONS
OUTPUT RESOLUTION
480
(STANDARD DEFINITION)
COMPOSITE VIDEO ANALOG AUDIO
(MONO) RCA
480I
720*
(ENHANCED DEFINITION)
COMPONENT VIDEO DIGITAL AUDIO (STEREO)
(RCA OR OPTICAL)
UP TO 720P
1080*
(HIGH DEFINITION)
COMPONENT VIDEO
VGA (15 PIN)
ANALOG AUDIO (STEREO)
DIGITAL AUDIO
(RCA OR OPTICAL)
UP TO 1080I
*ConsideredHighDenition
NOTE: ForanyvideosourcewithonlyanHDMIconnector,HDMItoComponentadapter,pn
57-863630-000,mustbepurchased.VGAtoComponentadapter,pn57-863631-000is
availableforthe720MODULATOR.Note:57-863633-000,VGAtoComponentadapter
ONLYFORTHE1080RESOLUTIONMODULATOR.
QUESTIONS ANSWERS
Quantity of separate sources to
display on overheads
NOTE: ProjectorsvideoisnotpartofSyncscoringandmustbesuppliedbycustomer.
Quantity of 480 resolution
modulator
Quantity of 720 resolution
modulator
Quantity of 1080 resolution
modulator
Distance from the Video
Distribution Center to the middle of
the bowling lanes at the overheads
Will the audio be connected to an
external audio system?
NOTE: Thismaycauseatimingissuebetweentheaudioandthevideosignals.Customeris
responsibleforsupplyingequipmenttocorrectissue.
