18 Sync Pre-Installation
Electrical Overview
ELECTRICAL SUB PANEL SPECIFICATIONS
IMPORTANT!: All sub panels and wiring MUST comply with local and national
electrical codes.
Pinsetter Sub panel - The Pinsetter sub panel provides power to the GS-Series pinsetters and other
Brunswick equipment. The pinsetter sub panel must be powered directly from the primary main
service sub panel or transformer and must be three phase. Non-Brunswick equipment including
electronic video games, arc welders, HVAC, compressors, etc., cannot share this sub-panel.
Scoring Sub panel - The Scoring sub panel is also directly powered from the main service sub panel
or transformer. The Scoring sub panel powers computer and electronic equipment. It is important the
power for the pinsetter sub panel is not mixed with the Scoring sub panel.
The ONLY type of equipment to be installed in the sub panels:
Pinsetter Sub panel
• GS-X Pinsetter
• Ball Lift
• Tel-E -Fou l
• Lane Machine
• Ball Polisher
• Lightworx
• Lanescape Video Masking Unit
Scoring Sub panel
• Peripheral Controller
• Overhead Monitors
• Display Controller
• HD Video Distribution Center
• Server Computer
• Client Computer
• Automated - Pinball Wizard
• Digital Signage
WARNING! Any Non-Brunswick equipment circuits located in these sub
panels will VOID ALL WARRANTY. This includes electronic video games, arc
welders, HVAC, compressors, etc.
