NETWORK SWITCH LOCATION
Curtain Wall and Overhead Structure
The switch for the curtain wall and the overhead structure can accommodate 38 lanes per switch. The
placement of the switch is indicated below for both the curtain wall and overhead structure. Ideally the
switch is installed in the center of the curtain wall and overhead structure for the number of lanes in the
center.
Location of Network Switch on Curtain Wall and Overhead Structure
1,2 3,4 5,6 7,8 9,10 11,12 13,14 15,16 17,18 19,20 21,22 23,24 25,26 27, 28 29,30 31,32 33,34 35,36 37,3 8
TOTAL NUMBER OF LANES IN BOWLING CENTER
2 X
4 X
6 X
8 X
10 X
12 X
14 X
16 X
18 X
20 X
22 X
24 X
26 X
28 X
30 X
32 X
34 X
36 X
38 X
40 X
NOTE: There is NO needforanadditionalelectricaloutlet.Thecurtainwallandoverhead
switchcanconnecttootherscoringequipmentforpower.
