Equipment Electrical Specications
CURTAIN WALL POWER OUTLETS
Electrical Information - Peripheral Controller
VOLTS HERTZ AC/DC PHASE
AMPS
PER UNIT
WATTS
BRANCH
CIRCUIT
CUSTOMER RESPONSIBILITY
100-130 50/60 AC 1 1 120
2 WIRES +
GROUND
INSTALL CIRCUIT WITH 2 OUTLET. NO
MORE THAN 5 LANE PAIRS PER 20 AMP
CIRCUIT.
200-220 50/60 AC 1 0.5 120
2 WIRES +
GROUND
INSTALL CIRCUIT WITH 2 OUTLET. NO
MORE THAN 8 LANE PAIRS PER 16 AMP
CIRCUIT.
Electrical Information - Sync Tablet Power Supply (Sync Tablet Installations Only)
VOLTS HERTZ AC/DC PHASE
AMPS
PER UNIT
WATTS
BRANCH
CIRCUIT
CUSTOMER RESPONSIBILITY
100-130 50/60 AC 1 2 240
2 WIRES +
GROUND
INSTALL CIRCUIT WITH 2 OUTLETS. NO
MORE THAN 5 LANES PAIRS PER 20 AMP
CIRCUIT.
200-240 50/60 AC 1 1 240
2 WIRES +
GROUND
INSTALL CIRCUIT WITH 2 OUTLETS. NO
MORE THAN 8 LANES PAIRS PER 16 AMP
CIRCUIT.
ElectricalInformation-CurtainWallNetworkSwitch(SpecicLanePairsOnly)
VOLTS HERTZ AC/DC PHASE
AMPS
PER UNIT
WATTS
BRANCH
CIRCUIT
CUSTOMER RESPONSIBILITY
100-130 50/60 AC 1 1.2 144
2 WIRES +
GROUND
THIS POWER REQUIREMENT INCLUDED
WITH THE PERIPHERAL CONTROLLER
AND OVERHEAD MONITOR POWER.
200-230 50/60 AC 1 0.6 144
2 WIRES +
GROUND
Electrical Information - HDLC Interface (GS-10, GS-92,GS-96, GS-98 Non-Direct Installations Only)
VOLTS HERTZ AC/DC PHASE
AMPS
PER UNIT
WATTS
BRANCH
CIRCUIT
CUSTOMER RESPONSIBILITY
100-130 50/60 AC 1 1 120
2 WIRES +
GROUND
INSTALL CIRCUIT WITH 2 OUTLET. NO
MORE THAN 16 LANES PAIRS PER 20
AMP CIRCUIT.
200-240 50/60 AC 1 0.5 120
2 WIRES +
GROUND
INSTALL CIRCUIT WITH 2 OUTLET. NO
MORE THAN 12 LANES PAIRS PER 16
AMP CIRCUIT.
