Brunswick Sync - Summary of Electrical Information

Sync Pre-Installation 51
Summary of Electrical Information
Equipment Operating
Voltage
Frequency
(Hertz)
AC
or
DC
Phase Max amps
per Unit
@120 VAC
Max Amps
per Unit
@240VAC
Wires
per Fused
Circuit
Power
Consumption
(Watts)
Connector
(Female)
Supplied by
Customer
Special Notes
32” Overhead LED
100-130 50/60 AC 1 .65 - 3
Typical - 30W
Max - 77W
120 Volt Outlet
2 Outlets needed per lane pair.
Outlets shared with Display
Controller Power Supply
200-240 50/60 AC 1 - .33 3
Typical - 30W
Max - 77W
230 Volt Outlet
40” Overhead LED
100-130 50/60 AC 1 1 - 3
Typical - 40W
Max - 121W
120 Volt Outlet
2 Outlets needed per lane pair.
Outlets shared with Display
Controller Power Supply
200-240 50/60 AC 1 - .51 3
Typical - 40W
Max - 121W
230 Volt Outlet
49” Overhead LED
100-130 50/60 AC 1 .83 - 3
Typical - 45W
Max - 99W
120 Volt Outlet
2 Outlets needed per lane pair.
Outlets shared with Display
Controller Power Supply
200-240 50/60 AC 1 - .42 5
Typical - 45W
Max - 99W
230 Volt Outlet
55” Overhead LED
100-130 50/60 AC 1 1.5 - 3
Typic al - 6 0W
Max - 176W
120 Volt Outlet
2 Outlets needed per lane pair.
Outlets shared with Display
Controller Power Supply
200-240 50/60 AC 1 - .75 5
Typic al - 6 0W
Max - 176W
230 Volt Outlet
Display Controller /
Power Supply
100-120 50/60 AC 1 2 - 3 240W 120 Volt Outlet
Outlet Shared with a lane pair of
overhead displays
200-240 50/60 AC 1 - 1 3 240W 230 Volt Outlet
