1.
Ground screws GND for screws M6
2.
LV-connector vehicle 12-pin (Code B)
3.
HV-connector (Code A)
4.
HV-connector (Code B)
12.7.3.1 Ground GND
INFORMATION
The ground screw must be connected with the ground of the vehicle or the
test stand.
W
e generally recommend to route the ground lines of all drive components together at one ground
point
. This minimizes the risk of potential differences, w
hich can lead to malfunctions of individual
drive components
!
The cable cross
-section of the ground line must correspond with the dimension of the HV-lines.
