BTS 2BV - Drawings; Drawings of the 2 BV2 Series; Drawings of the 2 BV5 Series

- 14 -
5 Drawings
5.1 Drawings of the 2BV2 series
Model.
Performance
curve
А
В
В1
Е
Н1
Н2
Н3
Н4
Н6
М
R
2BV2060
60V
455
186
140
125
90
118
126
186
37.5
244
203
2BV2061
61V
476
186
140
125
90
118
126
186
37.5
286
223
2BV2070
70V
565
223
160
140
100
128
222
210
33
314
260
2BV2071
71V
590
223
190
140
112
140
234
222
45
344
290
Model.
Performance
curve
P2
P3
S2
W1
W2
W3
D
N3.0
N4.2
N8.7
2BV2060
60V
250
195
Ø
10
110
25.5
21
G1
G3/8
G1/4
G3/8
2BV2061
61V
250
195
Ø
10
110
25.5
21
G1
G3/8
G1/4
G3/8
2BV2070
70V
270
215
Ø
12
110
33
27
G1½
G3/8
G1/4
G3/8
2BV2071
71V
300
240
Ø
12
110
33
27
G1½
G3/8
G1/4
G3/8
5.2 Drawings of the 2BV5 series
