7-2 2003 Buell P3: Electrical
HOME
TORQUE VALUES
ITEM TORQUE NOTES
Bank angle sensor 25-27
in-lbs
2.8-3.1 Nm Page 7-13
Battery terminal bolts 60-96
in-lbs
7-11 Nm Page 7-13
Circuit breaker bracket mounting
screw
25-27
in-lbs
2.8-3.1 Nm Page 7-31
Circuit breaker metal nuts 15-18
in-lbs
1.7-2.0 Nm Page 7-31
Circuit breaker nylon acorn 1-3
in-lbs
0.1-0.3 Nm Page 7-31
Headlamp housing mounting screws 12-14 ft-lbs 16-19 Nm Page 7-15
Ignition coil mounting screws 48-72
in-lbs
5-8 Nm Page 7-24
Ignition key switch bolts 48-72
in-lbs
5-8 Nm Page 7-15
Ignition module plate screws 10-20
in-lbs
1-2 Nm Page 7-20
Neutral indicator switch 36-60
in-lbs
4-7 Nm LOCTITE 243, Page 1-58
Rotor cup mounting fasteners 43-53
in-lbs
5-6 Nm Page 7-20
Rotor mounting bolts 90-110
in-lbs
10-12 Nm LOCTITE 242, Page 1-42
Sidestand switch fasteners 30-36
in-lbs
3-4 Nm Page 7-30
Spark plug 11-18 ft-lbs 15-24 Nm Page 7-3
Speedometer sensor screw 80-100
in-lbs
9-11 Nm Page 1-62
Stator mounting screws 30-40
in-lbs
3-5 Nm
T- 27 TORX with retaining compound, replace
after removal, Page 1-42
Switchgear housing screws, left side 25-33
in-lbs
3-4 Nm metric, Page 1-56
Switchgear housing screws, right side 25-33
in-lbs
2.8-3.7 Nm metric, Page 1-55
Tail lamp mounting locknuts 25-28
in-lbs
2.6-3.2 Nm metric, Page 1-51
Throttle position sensor fasteners 12-23
in-lbs
2-3 Nm Page 7-12
Timing inspection hole plug 10-15 ft-lbs 14-20 Nm Page 7-21
Voltage regulator mounting fasteners 48-72
in-lbs
5-8 Nm Page 1-43
